14" Screw Conveyor Rack and Pinion Gate - 3/16" Thickness | Curved Slide
$90.00
Price when purchased online
Free shipping
Free 30-day returns
Sold and shipped by explorerworld.com
We aim to show you accurate product information. Manufacturers, suppliers and others provide what you see here.
$90.00
Price when purchased online
Free shipping
Free 30-day returns
Sold and shipped by explorerworld.com
Free 30-day returns Details
Product details
| Management number | 211207610 | Release Date | 2026/04/04 | List Price | $36.00 | Model Number | 211207610 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
This 14" curved slide screw conveyor rack and pinion gate is crafted from premium 3/16" thick steel. It features a rack and pinion design, with cut tooth racks welded to the curved slide plate, engaging with a cut tooth pinion mounted on a shaft, operated by a handwheel. The curved slide aligns with the trough's contour, preventing material trapping in spouts above flat slides. Additionally, it can be operated using chain wheels or powered by electric motors, air, or hydraulic cylinders.
- Conveyor Diameter: 14 inches
- Part Number: 350-0840
- Steel Gauge: 3/16 inch
- Weight: 118 lbs
- Dimension A: 15.25 inches
- Dimension B: 19.25 inches
- Dimension C: 10.8125 inches
- Dimension D: 17.625 inches
- Dimension E: 3/16 inch
- Dimension F: 11.625 inches
- Slide Gauge (G): 10 inches
- Dimension H: 15.4375 inches
- Dimension J: 12 inches
- Dimension K: 12 inches
- Dimension L: 2.625 inches
| Color | Dark Grey |
|---|---|
| Room Type | Industrial/Commercial |
| Brand Name | USA ROLLER CHAIN |
| Finish Types | Unfinished |
| Material Type | High-quality steel |
| Mounting Type | Handwheel (not included with assembly) |
| Additional Features | compatibility, power, supported_standards, temperature_limits |
| Recommended Uses For Product | Material Handling, Industrial Use |
